| MODEL | THC-20 | THC-30 | THC-40 | THC-50 | |
|---|---|---|---|---|---|
| Temp. Range & Humid. Range | -40℃ ~ +80℃ & 30% ~ 95% RH | ||||
| Temp. & Humid. Accurascy | ±1℃ & ±3℃ RH | ||||
| Chamber Size | In | 2000x2000x2000 | 3000x3000x2000 | 4000x4000x2000 | 5000x5000x2000 |
| Out | 2200x2700x2600 | 3200x3700x2600 | 4200x4700x2600 | 5200x5700x2600 | |
| Refrigerator Unit | 1500x1000x2600 | 2000x1000x2600 | 3000x1200x2600 | 3500x1500x2600 | |
| Control Box WxDxH (mm) | 800x600x2000 | ||||
| Material | In) SUS 304 Out)Urethane Panel | ||||
| Temp. & Humid. Controller | Digital P.I.D Program Control System (NEX 1200 / Touch Screen) | ||||
| Temp. Sensor | PT 100Ω | ||||
| Humid. Sensor | E + E91 (Direct Reading Style) | ||||
| Heater | Dry | 24kW | 48kW | 90kW | 120kW |
| Humid. | 10kW | 20kW | 36kW | 50kW | |
| Refrigerator | 7.5HP x 2Set | 10HP x 2Set | 15HP x 2Set | 20HP x 2Set | |
| 3HP(For Dehumidification) | 5HP(For Dehumidification) | 7.5HP(For Dehumidification) | 7.5HP(For Dehumidification) | ||
| Circulation Motor | 1HP x 4Set | 1HP x 6Set | 2HP x 8Set | 3HP x 10Set | |
| Safety Device | Refrigerator over load relay (냉동기 과부하보호기), EMC S/W (비상스위치), E.L.B (누전차단기), Over heat protect (온도과승방지기), EOCR (모터과부하경보기) |
||||
| Accessories | Power and Siganal Line supplies inside the chamber, Variety of utilities | ||||
| Power Source | 380V, 3Ǿ, 51kW(80A) | 380V, 3Ǿ, 90kW(135A) | 380V, 3Ǿ, 166kW(250A) | 380V, 3Ǿ, 225kW(350A) | |
