Precision Water Bath
Compact Desing & Elepant Appearance!
Features
1. Accurate tmperature control is possible by using digital P.I.D temperature controllers.
2. Uniform temperature control operation is possible by using the Water Circulation Pump.
Specification
← Scroll Left/Right →
| MODEL |
VT-WB 100 |
VT-WB 200 |
| Temperature Range |
RT ~ 99°C |
RT ~ 99°C |
| Dimension |
In(WxDxH) |
1000 x 600 x 400mm |
600 x 400 x 400mm |
| Out(WxDxH) |
1500 x 700 x 800mm |
1000 x 500 x 900mm |
| Material |
In |
Stainless Steel |
Stainless Steel |
| Out |
Steel Plate Painting |
Stainless Steel |
| Temperature Accuracy |
±0.2℃ at 90℃ |
±0.2℃ at 90℃ |
| Heater Capacity |
SUS Pipe Heater(6Kw x 3ea =18Kw) |
SUS Pipe Heater(3Kw x 3ea =9Kw) |
| Safety Device |
ELB, EOCR, Dizzet Fuse |
ELB, EOCR, Dizzet Fuse |
| Power Source |
30Ø AC 220V or 380V 50/60Hz |
30Ø AC 220V or 380V 50/60Hz |
* External appearance & type and specifiation may be to change without advance notice to enhance the performance of equipment.
